TR7100/TR7100EP PCI-1751卡TR7100/TR7100EP PCI-1751卡
PCI-1751是一款基于PCI總線的48位數字量I/O卡.其48位被分為6個8位的I/O端口,用戶可以通過軟件對每個端口進行配置.
Power Consumption
OS Support
Dimensions
Bus
I/O Connectors
Operating Temperature
Programming Language
Max.: 5 V @ 1 A
32-bit/64-bit Windows 7/8/10, and Linux
175 x 100 mm (6.9" x 3.9” )
PCI
1 x 68-pin SCSI female connector
0 ~ 60°C (32 ~ 140° F)
C#,C++,LabVIEW,VB.Net,BCB,MFC,VB6,Delphi,Java,Matlab,Qt
Resolution
Channels
Max. Input Frequency
16 bis
3
10 MHz
Input Channels
Output Channels
48 (shared)
48 (shared)
